Dimensions (Inside):

Any length X either 88-3/4” or 94-3/4” width; choice of 84”, 89”, 95”, 101”, or 107” height

Exterior:

Smooth .040” pre-painted white aluminum; extruded aluminum corner posts, roof radius, and upper and lower side rails

Roof:

Mill-finished aluminum

Side Posts:

2” aluminum extruded Z-posts on 16” centers with an inner-angle thermobarrier

Roof Bows:

2” aluminum extruded H-beams with thermobarrier

Floor:

Extruded aluminum box floor or aluminum treadplate bright; trough with drain holes at front and rear; 20 ga. galvanized steel sub-floor

Interior Lining:

Kemlite or galvanized steel

Rear Door:

Whiting pre-painted white 1-1/2” Tempguard roll-up rear door with inside release and extruded aluminum door frame

Insulation:

FIP (foamed in place) : 3” in front and side walls and ceiling; 4” in floor between crossmembers

Understructure:

4” galvanized steel crossmembers on 12” centers and 6” steel structural channel longitudinal runners

Additional  Equipment:

• Reinforced bulkhead and opening for refrigeration unit

• ICC step bumper

• Rubber dock bumpers

• Two dome lights

• Undercoating

• 12” extruded aluminum scuff rail

• Single center rear door

• Double full-open rear doors

• Variety of bumper styles

• Triple full-open rear doors

• Liftgate or slide-out ramp

• Refrigeration unit (provided and installed)
